N Fun 30 Specifications
Main Specs
| Length, m | 9 |
| Beam, m | 2.92 |
| Draft, m | 1.6 |
Classification
| Hull Type | Monohull |
| Type by Usage | Daysailer, Performance Cruiser, Racing |
| CE Class | B - Sea |
| Hull Material | Fiberglass / GRP |
| Design | Modern / Mainstream |
| Deck Arrangement | Sport cockpit |
Rigging and Keel
| Rig | Single-masted (sloop) |
| Keel | Fixed, Lifting, Lifting keel |
| Max Draft, m | 1, 8 |
| Min Draft, m | 5 |
| Sails | mainsail – 25 m² jib – 21 m² spinnaker – up to 100 m² |
Cabins & Passenger Capacity
| Max People on Board | 6 |
| Cabins | 1 |
| Bathrooms | 1 |
Engine
| Engine Type | Diesel, Electric, Outboard, Petrol |
| Engine Model | ePropulsion, Mercury, Oceanvolt, Yanmar |
| Engine Power | 8-21 |
Manufacturer Information
| Shipyard | N Fun Yachting |
| Country | Poland |
| Model | 30 |
| Designer | Eugeniusz Ginter |
| Period of manufacturing | 2014 - now |
Technical Specs
| LOA, m | 9.4 |
| LOD, m | 9 |
| LWL, m | 8.92 |
| Sail Area (S.A.), m² | 45 |
| Ballast, kg | 700 |
Sailboat Calculations
Hull Speed Max Formula
HS = 1.34 × √LWL (in feet)
The maximum speed of a displacement hull (referring to a hull that travels through the water rather than on top of it, e.g. planing).
HS = 1.34 × √LWL (in feet)
The maximum speed of a displacement hull (referring to a hull that travels through the water rather than on top of it, e.g. planing).
Pounds per Inch Immersion Formula
PPI = LWL Area × 5.333
The weight required to sink the yacht one inch. Calculated by multiplying the LWL area by 5.333 for sea water or 5.2 for fresh water.
PPI = LWL Area × 5.333
The weight required to sink the yacht one inch. Calculated by multiplying the LWL area by 5.333 for sea water or 5.2 for fresh water.
| Hull Speed Max, knots | 7.25 |
| Pounds per Inch Immersion, lbs/inch | 1,001.76 |
Rig and Sail Particulars
S.A. Fore Formula
S.A. Fore = I * J / 2
This is the area of the fore triangle, calculated by multiplying I and J and dividing by 2.
S.A. Fore = I * J / 2
This is the area of the fore triangle, calculated by multiplying I and J and dividing by 2.
S.A. Main Formula
S.A. Main = P * E / 2
This is the area of the main triangle, calculated by multiplying P and E and dividing by 2.
S.A. Main = P * E / 2
This is the area of the main triangle, calculated by multiplying P and E and dividing by 2.
S.A. Total Formula
S.A. Total = S.A. Fore + S.A. Main
This is the sum of the fore and main sail areas.
S.A. Total = S.A. Fore + S.A. Main
This is the sum of the fore and main sail areas.
Forestay Length Formula
Est. Forestay Length = √(I² + J²)
This is the length of the forestay, calculated using the Pythagorean theorem.
Est. Forestay Length = √(I² + J²)
This is the length of the forestay, calculated using the Pythagorean theorem.
| I, m | 10.66 |
| J, m | 3.6 |
| P, m | 10.95 |
| E, m | 4 |
| S.A. Fore, ft²m² | 206.54 19.19 |
| S.A. Main, ft²m² | 235.73 21.9 |
| S.A. Total, ft²m² | 442.27 41.09 |
| Est. Forestay Length, ftm | 36.91 11.25 |
