Elan E4 Specifications

Main Specs
Length, m 10.6
Beam, m 3.5
Draft, m 2.15
Displacement, kg 5300
Classification
Hull Type Monohull
Type by Usage Performance Cruiser
CE Class A - Ocean
Hull Material Fiberglass / GRP
Design Modern / Mainstream
Deck Arrangement With mediterranean cockpit
Rigging and Keel
Rig Single-masted (sloop)
Keel Fixed
Sails mainsail – 40 m² jib ( self-tacking) – 35 m² gennaker – 128 m²
Cabins & Passenger Capacity
Cabins 2
Berths for Guests 6
Bathrooms 1
Tanks Capacity
Fuel capacity, l 75
Water tank, l 185
Manufacturer Information
Shipyard Elan
Country Slovenia
Series E-Line
Model E4
Period of manufacturing 2013 - now
Sailboat Calculations
× Capsize Screening Formula
CSF = Beam ÷ (Disp in cubic ft)^(1/3)
Designed to determine if a boat has blue water capability. The CSF compares beam with displacement since excess beam contributes to capsize and heavy displacement reduces capsize vulnerability. The boat is better suited for ocean passages (vs coastal cruising) if the result of the calculation is 2.0 or less. The lower the better.
Capsize Screening Formula 2.03ℹ️
