Sidney Company (USA)
Loa 17 Specifications
Main Specs
| Length, m | 5.18 |
| Draft, m | 1.37 |
| Displacement, kg | 318.00 |
Classification
| Hull Type | Cbrd w/outboard rudder |
| Hull Material | FG |
Rigging and Keel
| Rig | Fractional Sloop |
| Keel | Steel centerboard |
| Max Draft, m | 1.37 |
| Min Draft, m | 0.15 |
Manufacturer Information
| Shipyard | Sidney Company (USA) |
| # Built | 399 |
| Designer | Sidney Blinder |
| Period of manufacturing | 1961 - 1961 |
Technical Specs
| LOA, m | 5.18 |
| Sail Area (S.A.), m² | 13.94 |
| Ballast, kg | 45.00 |
Sailboat Calculations
S.A. / Displacement Formula
SA/D = SA (ft²) ÷ [Disp (lbs) / 64]^0.666
A sail area/displacement ratio below 16 would be considered under powered; 16 to 20 would indicate reasonably good performance; above 20 suggests relatively high performance.
SA/D = SA (ft²) ÷ [Disp (lbs) / 64]^0.666
A sail area/displacement ratio below 16 would be considered under powered; 16 to 20 would indicate reasonably good performance; above 20 suggests relatively high performance.
Ballast / Displacement Formula
Bal./Disp = ballast (lbs)/ displacement (lbs)*100
A Ballast/Displacement ratio of 40 or more translates into a stiffer, more powerful boat that will be better able to stand up to the wind.
Bal./Disp = ballast (lbs)/ displacement (lbs)*100
A Ballast/Displacement ratio of 40 or more translates into a stiffer, more powerful boat that will be better able to stand up to the wind.
| S.A. / Displacement | 30.47 |
| Ballast / Displacement, % | 14.15 |
