Lagoon 50 Specifications

Main Specs
Length, m 14.75
Beam, m 8.1
Draft, m 1.4
Displacement, kg 20830
Classification
Type by Usage Cruiser
Hull Material Fiberglass / GRP
Design Modern / Mainstream
Deck Arrangement Other
Rigging and Keel
Rig Single-masted (cat)
Keel Fixed
Cabins & Passenger Capacity
Cabins 3
Berths for Guests 6
Bathrooms 2
Tanks Capacity
Fuel capacity, l 1
Water tank, l 480
Manufacturer Information
Shipyard Lagoon
Country France
Model 50
Period of manufacturing 2017 - 2022
Sailboat Calculations
× Capsize Screening Formula
CSF = Beam ÷ (Disp in cubic ft)^(1/3)
Designed to determine if a boat has blue water capability. The CSF compares beam with displacement since excess beam contributes to capsize and heavy displacement reduces capsize vulnerability. The boat is better suited for ocean passages (vs coastal cruising) if the result of the calculation is 2.0 or less. The lower the better.
Capsize Screening Formula 2.97ℹ️
