Hallberg-Rassy 50 Specifications

Main Specs
Length, m 16.34
Beam, m 5.02
Draft, m 2.35
Displacement, kg 21000
Classification
Hull Type Monohull
Type by Usage Cruiser
CE Class A - Ocean
Hull Material Fiberglass / GRP
Design Modern / Mainstream
Deck Arrangement With central / scandinavian cockpit
Rigging and Keel
Rig Single-masted (sloop)
Keel Fixed
Cabins & Passenger Capacity
Cabins 3
Berths for Guests 7
Bathrooms 2
Tanks Capacity
Fuel capacity, l 1
Water tank, l 800
Manufacturer Information
Shipyard Hallberg-Rassy
Country Sweden
Series Center Cockpit
Model 50
Period of manufacturing 2021 - now
Sailboat Calculations
× Capsize Screening Formula
CSF = Beam ÷ (Disp in cubic ft)^(1/3)
Designed to determine if a boat has blue water capability. The CSF compares beam with displacement since excess beam contributes to capsize and heavy displacement reduces capsize vulnerability. The boat is better suited for ocean passages (vs coastal cruising) if the result of the calculation is 2.0 or less. The lower the better.
Capsize Screening Formula 1.84ℹ️
